PulseIQ™ Technology Allows Customization of Encoder Specifications to Meet Your Needs

Introducing the HS35iQ Encoder with PulseIQ™ Technology. Program encoder output to match exact requirements. Adjust encoder resolution, phase, index pulse output and more. Simplify inventory and stock programmable encoders.

One Encoder, Programmed to Your Needs

• Adjust encoder resolution from 1 to 20,000 PPR in one PPR increments.
• Change phase direction, index pulse output type (single-ended or differential), output voltage (TTL or HTL) and more.
• Keep inventory of just one part number and change encoder specifications to meet application requirements.

HS35iQ with PulseIQ™ Technology

• Customize specifications with programmable resolution, phase, index pulse and more. Up to 20,000 PPR incremental quadrature output.
• LED status lights provide indication of common encoder faults including over-temperature, shaft slippage, cable integrity, insufficient voltage and electronic failure.
• Rugged design withstands up to 400g shock, 20g vibration. Enclosure rating IP67, operating temp range -40°C to +100°C.
• Imperial and Metric bore sizes up to 1-1/4” or 30mm.
